  • LC65002
    RGB LightCrafter 6500
    - High throughput RGB optical engine
    - Sophisticated LED cooling system
    - TI LightCrafter 6500 board
    - HD resolution 1920 x 1080
    - RGB LED electronic driver
    Optecks' full-featured version:
  • Ray70
    RAY 70
    HD Optics
    High Brightness
    Optical Module
  • RGB_Slide_LZ
    Optecks offers design and manufacturing of optical engines
    Highest optical performance
    Optical Engines
    Compact opto-mechanical system
  • slide1.4
    DLP NIRscan Nano
    with Transmissive Module
  • tm3
    Convert your reflective DLP NIRscan Nano EVM
    Transmission Module
    to Transmissive
  • LA8
    Light Animator
    Instantly display and animate the images on the DMD

Our Services

Spectroscopy

3D Printing

3D Machine Vision

3D Display

Near Eye Display

About Optecks

About top image

About Optecks



Xpert Accordion

Who We Are

Optecks is a Texas Instruments Authorized Design House based in Tulsa, Oklahoma dedicated to providing both standard and customized solutions for DLP-based systems in a wide variety of applications

What We Do

Optecks provides optical, electronic and software solutions to  your applications in the areas of displays, Spectroscopy, 3D machine vision, 3D printing, 3D display and Lithography.

Why Choose Us ?

Optecks is uniquely positioned to provide the technical expertise and resources needed to develop Optical, Electronic and Software solutions to your application

Our Goal

Optecks's is dedicated to provide the best solutions possible for DLP-based applications.

Our Portfolio

  • All
  • DLP Optical Engines
  • Spectrometers
  • Software Solutions
  • RAY 70 Optical Module
  • RAY LED Monochromatic Optical Module
  • RAY 65S Optical module
  • Transmissive Module EVM
  • 2 in 1 DLP NIRscan Nano EVM
  • Portfolio Title
  • Portfolio Title
  • Portfolio Title

About Bottom Text

How DLP works?

At the heart of every DLP chipset is an array of highly reflective aluminum micromirrors known as the digital micromirror device (DMD). The DMD is an electrical input, optical output micro-electrical-mechanical system (MEMS) that allows developers to perform high speed, efficient, and reliable spatial light modulation. Using TI's proven semiconductor manufacturing capabilities, each DMD contains up to 2 million individually controlled micromirrors built on top of an associated CMOS memory cell. Since the first DLP chipset was sold in 1996, TI has produced more than 35 million DMDs for customers around the world.

During operation, the DMD controller loads each underlying memory cell with a '1' or a '0'. Next, a mirror reset pulse is applied, which causes each micromirror to be electrostatically deflected about a hinge to the associated +/-12° state. The deflection angle of these two valid states is very repeatable due to a physical stop against two spring tips. In a projection system, the +12° state corresponds to an 'on' pixel, and the -12° state corresponds to an 'off' pixel.Grayscale patterns are created by programming the on/off duty cycle of each mirror, and multiple light sources can be multiplexed to create full RGB color images. In other applications, the +/-12° states offer two general purpose output ports with a pattern and its inverse

how dlp works

clients logos table

Optecks’ Research funded in part by:

OCAST Logo

Optecks is an Authorized Design House at:

Texas Instruments Logo
